| Type: |
Acars / Digital to Analogue Conversion Unit |
| Receive modes: |
APCO Project 25 digital voice signal
(Non encrypted signal only)
Analogue Narrow FM signal |
| -Off frequency adjustment: |
Automatic (AFC) |
| Signal modulation: |
± 20% from the Specifications
(Automatic adjustment) |
| Squelch: |
Level squelch (Analogue mode)
adjustable squelch level |
| Power requirement: |
11 - 16 VDC, 140 mA
(at 12 V DC) typical |
| Serial port: |
RS-232C 9600bps Asynchronous
8 bit, Non parity, 1 stop bit |
| External Speaker output: |
3.5 mm mono |
| Headphone jack |
3.5 mm stereo type (signal output is mono) |
| Weight: |
Approximately 580 g (1.3lb) |
| Dimensions |
156(D) x 100(W) x 32(H) mm |
| Other: |
Three modes are supported:
1. APCO25 conventional analogue demodulation, no trunking
2. ASTRO25 analogue 3600bps
3. Digital 9600bps |
| Related Documents: |
Manual (130 kb) |
