| Type: | Amateur VHF/UHF Transceiver |
| Frequency Range: | 144-146 / 430-440 MHz |
| Modes: | FM |
| RF Power output: | 300 mW |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 3.7 VDC internal Li-Io |
| Current Drain: | RX: Max 40 mA TX: Max 300 mA |
| Aerial Input: | 50 ohms |
| Dimensions (W*H*D): | 56*94*11 mm |
| Weight: | 85 gr (Battery included) |
| Manufactured: | 199x-200x |
| Other: | |
| Related Documents: |
