| Type: |
HF/VHF/UHF Receiver/Scanner |
| Frequency Range: |
30-253.8/255-262/266-271/275-380.2/381.325-412/414-470 MHz |
| Modes: |
Analog:
AM / NAM / FM / NFM (Not between 76-108 MHz)
WFM (76-108 MHz only)
DV modes (Not between 76-108 MHz):
D-Star, DCR/NXDN, DMR/MotoTRBO, dPMR, Yaesu C4FM "Fusion"
Data modes (Not between 76-108 MHz): ACARS, AIS, B54, T98, T102 |
| Memory Channels: |
999 regular in 26 banks
50 search pairs
Alpha tags (14 or 28 characters, depending on font size) |
| Search Banks: |
N/A |
| Priority Channels: |
N/A |
| Scan Speed: |
N/A |
| Search Speed: |
N/A |
| Increment Steps: |
1/3.125/5/6.25/8.33/10/12.5/15/20/25/3/50/100/125/150/200 KHz |
| Scan Delay: |
N/A |
| Voltage: |
3.6 VDC (Li-Ion battery pack)
or 5 VDC external |
| Current Drain: |
150-500 mA |
| Impedance: |
50 ohms, SMA |
| Dimensions (W*H*D): |
58 x 110 x 32 mm
2.28 x 4.33 x 1.26 inches |
| Weight: |
260 g (9.17 oz), with EBP-114 and Antenna |
| Manufactured: |
2007-200x |
| Other: |
CTCSS/PL and DCS decoder. 2" color TFT (320*240 pixels). GPS receiver for
positioning and location based scanning. USB-C jack for charging, external power
and PC programming. The headphone cord can also be used as an antenna. Voice
inversion descrambler. F-Count (Tunes to nearby transmissions, similar to Bearcat
Close Call). 12 KHz IF output. IP67 resistant. DSP/SDR technology |
| Related Documents: |
User Manual (5.1 MB)
Review Practical Wireless September-2025 |
