| Type: |
Amateur VHF/UHF Transceiver |
| Frequency Range: |
144-146 / 430-440 MHz
RX: 87.5-108 / 108-174 / 335-480 MHz |
| Modes: |
TX: FM/NFM
RX: AM/FM/NFM/WFM |
| RF Power output |
| Hi: 50/35 W
Mid: 10/10 W
Lo: 5/5 W |
Sensitivity:
Main band: 0.2 uV or better (-12 dB SINAD)
Sub band: 0.25 uV or better (-12 dB SINAD) |
|
Selectivity:
FM, -6 dB: 12 KHz or more, -60 dB: 28 KHz or less
NFM, -6 dB: 6 KHz or more, -60 dB: 14 KHz or less |
|
Image rejection:
| N/A |
|
Voltage:
| 13.8 VDC |
|
Current Drain:
RX: 400-600 mA
TX: Max 11 A |
|
Aerial Input:
| 50 ohms, SO-239 |
|
Dimensions (W*H*D):
| 140 x 40 x 185 mm |
|
Weight:
| 1 Kg |
|
Manufactured:
| 2002-200x |
|
Other:
202 memories. Detachable control head. Theft alarm. CTCSS +ACY- DCS. Twin RX.
1200/9600 bd packet and GPS option (EJ-50U). 10F3 digital voice board (EJ-47U) option
(requires at least two similarly equipped radios) |
|
