Azden AZ-21
| Type: |
Amateur HF Transceiver |
| Frequency Range: |
144-148 MHz |
| Mode: |
FM |
| RF Power Output: |
Hi: 5 W
Lo: 0.5 W |
| Sensitivity: |
0.16 µV (12 dB SINAD) |
| Selectivity: |
12 kHz (-6 dB), 30 kHz (-60 dB) |
| Image Rejection: |
60 dB |
| Voltage: |
6.3-16 VDC |
| Current Drain: |
RX: ?? mA
TX: ?? A |
| Aerial Input: |
50 ohms |
| Dimensions (W*H*D): |
60 x 174 x 33 mm |
| Weight: |
550 gr |
| Manufactured: |
Japan, 20xx-20xx |
| Other: |
|
| Related Documents: |
|
|
