| Type: |
HF/VHF/UHF Receiver/Scanner |
| Frequency Range: |
Band A: 0.1-3305 MHz
Band B: 108-520 MHz
(Cellular blocked in the US) |
| Modes: |
Analog:
AM / AM-N / FM / NFM / WFM / SSB / CW
DV Modes:
APCO P25 ......... C4FM ...... IMBE
D-Star................. GMSK ...... AMBE
DCR/NXDN ...... C4FM ...... AMBE+2
dPMR ................ C4FM ...... AMBE+2
|
| Memoris: |
2000 Regular
200 Auto Write
50 Scan Edges
300 GPS
Non-volatile EEPROM Storage |
| Voltage: |
3.6 VDC (BP-287) or 5 VDC external (USB) |
| Current Drain: |
100-330 mA (Single watch. GPS, Recording and Backlite off. |
| Aerial Input: |
50 ohms: SMA |
| Dimensions (W*H*D): |
58 x 143 x 30 mm |
| Weight: |
310 gr (10.9 oz) with Antenna and BP-287 |
| Manufactured: |
Japan: 2018-2021 (Discontinued) |
| Other: |
CTCSS/PL, DTCS. Bluetooth
Dual watch (with some limitations)
GPS. 2.3" dot-matrix LCD
Digital Recording on Micro-SD
IP57 Dust and Water Protection
VSC. Speech Function
ANL, NB. RF Gain. Attenuator
Clock. |
| Related Documents: |
User Manual (2.9 MB)
Advanced Manual (3.0 MB)
Sales Leaflet (1.7 MB) |
