Icom IC-R71
| Type: |
HF Receiver |
| Frequency Range: |
0.1-30 MHz |
| Modes: |
AM/SSB/CW/RTTY (FM option) |
| Sensitivity: |
SSB/CW/RTTY: <0.15 µV (0.1-1.6 MHz = 1 µV) for 10 dB S + N/N
AM: <0.5 µV (0.1-1.6 MHz = 3 µV)
|
| Selectivity: |
SSB/CW/RTTY: 2.3 kHz at -6 dB (adjustable at min 500 kHz)
4.2 kHz at -60 dB
CW-N, RTTY-N: 500 Hz at -6 dB
1.5 kHz at -60 dB
AM: 6 khz at -6 dB (adjustable at min 2.7 kHz)
15 kHz at -50 dB
|
| Image rejection: |
>60 dB |
| Voltage: |
Mains (13.8 VDC option) |
| Current Drain: |
? mA |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
286*111*276 mm |
| Weight: |
7.5 Kg |
| Manufactured: |
198x-198x |
| Other: |
|
| Related Documents: |
Service Manual (29.8 MB) |
|
