Icom IC-271E

Type: Amateur VHF Transceiver
Frequency Range: 144-146 MHz
Modes: FM/SSB/CW
RF Power output: Max 25 W
Sensitivity: N/A
Selectivity: N/A
Image rejection: N/A
Voltage: 13.8 VDC
Current Drain: RX: ? A
TX: Max 6 A
Aerial Input: 50 ohms, SO-239
Dimensions (W*H*D): 285*110*275 mm
Weight: 5.2 Kg
Manufactured: 1983-19xx
Other:
Related Documents:
