| Type: |
Amateur HF Transceiver |
| Frequency Range: |
RX: 0.030-29.999999 MHz
TX: 1.6-29.999999 MHz |
| Modes: |
USB, LSB, CW, RTTY (FSK), AM |
| RF Power output: |
100 W |
| Memories: |
99 (duplex) + 1 call channel |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
13.8 V DC ±15% (negative ground) |
| Current Drain: |
RX: Stand-by 1.3 A max audio 2.0 A
TX: max. power 20.0A |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions: |
240(W) x 95(H) x 239(D) mm |
| Weight: |
3.8 kg |
| Manufactured: |
19xx-19xx |
| Other: |
|
| Related Documents: |
User Manual (2.64 MB)
Brochure (237 Kb) |
