| Type: |
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-148 / 420-440 MHz (USA)
RX: 0.5-999 MHz |
| Modes: |
RX: AM/FM/NFM and DV (GMSK 4.8 kbps voice)
TX: FM/NFM and DV (GMSK 4.8 kbps voice) |
| RF Power output: |
Hi: 5 / 5 W
Lo: 500 / 500 mW |
| Receiver system: |
AM/FM: Dual-conversion, WFM: Triple-conversion superheterodyne
1st IF: 61.65 MHz (AM/FM A-band), 59.25 MHz (WFM A-band), 46.35 MHz (AM/FM B-band)
2nd IF: 450 KHz (AM/FM), 13.35 MHz (WFM)
3rd IF: 1.95 MHz (WFM) |
| Memories: |
1304 |
| Frequency Steps: |
5/6.25/8.33/9/10/12.5/15/20/25/30/50/100/125/200 KHz |
| Scan Rate: |
N/A |
| Voltage: |
7.4 VDC (battery pack)
10-16 VDC (external) |
| Current Drain: |
RX: ? mA
TX: 0.8-2.1 A |
| Impedance: |
50 ohms, SMA |
| Dimensions: |
58(W) x 103(H) x 24(D) mm |
| Weight: |
300 gr (without batteries and antenna) |
| Manufactured: |
2006-200x |
| Other: |
D-Star concept. CTCSS and DTCS. Twin RX |
| Related Documents: |
User Manual (1.66 MB) |
