| Type:
|
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-146 / 430-440 MHz (Europe)
TX: 144-148 / 430-440 MHz (USA)
RX: 0.5-999 MHz
5/6.25/8.33/9/10/12.5/15/20/25/30/50/100/125/200 KHz steps |
| Modes: |
RX: AM/FM/NFM and GMSK (4.8 kbps voice)
TX: FM/NFM and GMSK (4.8 kbps voice) |
| RF Power output: |
Hi: 5 / 5 W
Lo: 500 / 500 mW |
| Frequency Steps: |
N/A |
| Voltage: |
7.4 VDC (battery pack)
10-16 VDC (external) |
| Current Drain: |
RX: ? mA
TX: 0.8-2.1 A |
| Aerial Input: |
50 ohms, SMA |
| Dimensions (W*H*D): |
58*103*24 mm |
| Weight: |
300 gr (without batteries and antenna) |
| Manufactured: |
2006-200x |
| Other: |
D-Star concept. 1304 memories with alpha tags.
CTCSS and DTCS. Twin RX |
| Related Documents: |
|
