Trio 9R-59D
| Type: |
VHF/UHF Receiver/Scanner |
| Frequency Range: |
550kHz to 30MHz in 4 Bands
Band 1: 0.55-1.6 MHz
Band 2: 1.6-4.8 MHz
Band 3: 4.8-14.5 MHz
Band 4: 10.5-30 MHz |
| Modes: |
AM/AM-ANL/SSB-CW |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
230VAC/50Hz or 115VAC/60Hz |
| Current Drain: |
?-? mA |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
381 x 254 x 178 mm |
| Weight: |
8.4 Kg |
| Manufactured: |
Japan, 1968-1969 |
| Serial Number: |
0 3 0 4 6 1 |
| Modifications: |
None |
| Other: |
Valves |
| Related Documents: |
|
 |
