Kenwood R-599D
| Type: |
HF Receiver |
| Frequency Range: |
10-160 m (2m & 6m options) |
| Modes: |
AM/FM/SSB/CW |
| Sensitivity: |
AM (10 dB S+N/N):
1.8-28 MHz: 1.5 uV
50 MHz: 3 uV
144 MHz: 3 uV
SSB (10 dB S+N/N):
1.8-28 MHz: 0.25 uV
50 MHz: 0.5 uV
144 MHz: 0.5 uV |
| Selectivity: |
AM: 5 KHz (-6 dB), 12 KHz (60 dB)
FM: 20 KHz (-6 dB), 120 KHz (-60 dB)
SSB: 2.4 KHz (-6 dB), 4.4 KHz (-60 dB)
CW: 500 Hz (-6 dB), 1.5 KHz (-60 dB) |
| Image rejection: |
>50 dB |
| Voltage: |
12-15 VDC or Mains |
| Current Drain: |
Max 1 A |
| Aerial Input: |
50-75 ohms, SO-239 |
| Dimensions (W*H*D): |
270*140*310 mm |
| Weight: |
5.7 Kg |
| Manufactured: |
Japan, 1976-1979 |
| Other: |
Matching Cmpanion to the T-599D Transmitter |
| Related Documents: |
User Manual (3.64 MB) |
|
