| Type: |
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-148 / 222-225 / 438-450 MHz
RX: 0.1-1300 MHz (Cellular blocked) |
| Modes: |
TX: FM
RX: AM/FM/SSB/CW |
| RF Power output: |
Hi: 5/5/5 W
Lo: 0.5/0.5/0.5 W
El: 50/50/50 mW |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
Internal: 5-7.5 VDC
External: 12-16 VDC |
| Current Drain: |
RX: ? mA
TX: Max ? A |
| Aerial Input: |
50 ohms, SMA |
| Dimensions (W*H*D): |
58*87*30 mm (with lithium-ion battery pack) |
| Weight: |
250 gr (with lithium-ion battery pack) |
| Manufactured: |
2001-200x |
| Other: |
4*LR6 battery case option. 435 memories
Built-in ferrite bar antenna for 0.1-7 MHz
VOX. 9K6 packet ready. Twin RX |
| Related Documents: |
User Manual (908 kb) |
