Trio TR-9300
| Type: |
Amateur VHF Transceiver |
| Frequency Range: |
50-54 MHz |
| Modes: |
AM/FM/USB/CW (LSB option) |
| RF Power output: |
Hi: 10 W
Lo: 1 W |
| Sensitivity: |
AM: 0.7 uV (10 dB S/N)
FM: 0.2 uV (12 dB SINAD)
SSB/CW: 0.16 uV (10 dB S/N) |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: ? mA
TX: ? A |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
170*68*260 mm |
| Weight: |
2.4 Kg |
| Manufactured: |
198x-198x |
| Other: |
|
| Related Documents: |
|
|
