| Type: | Amateur Handheld Transceiver |
| Frequency Range: | 144-146 MHz (138-174 MHz) 5 / 10 / 12.5 / 20 / 25 / 50 KHz steps |
| Mode: | FM |
| RF Power output: | Hi: 5 W Mid: 2.5 W Lo: 350 mW |
| Sensitivity: | 0.16 uV (12 dB SINAD) |
| Selectivity: | N/A |
| Image rejection: | >60 dB |
| Voltage: | 7.2 VDC (battery), 5-16 VDC (external) |
| Current Drain: | RX: 13/35 mA (save/stby) TX: Max 950 mA |
| Aerial Input: | 50 ohms, BNC |
| Dimensions (W*H*D): | 55*84*31 mm |
| Weight: | 185 gr |
| Manufactured: | xxxx-xxxx |
| Other: | 40 memories |
