| Type: | HF/VHF Receiver/Scanner |
| Frequency Range: | 0.15-108 MHz |
| Modes: | AM/WFM |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 6 VDC (4 x LR6 or external adapter) |
| Current Drain: | ? mA |
| Aerial Input: | 50 ohms, TNC or telescopic whip and internal ferrite bar |
| Dimensions (W*H*D): | 90*182*50 mm |
| Weight: | 650 gr |
| Manufactured: | 19xx-19xx |
| Other: | |
| Related Documents: | Service Manual (9.8 MB) |
