| Type: |
HF Receiver |
| Frequency Range: |
10-80 m (in 7 Bands)
80 m: 3.5-4.1 MHz
40 m: 6.9-7.5 MHz
20 m: 13.9-14.5 MHz
15 m: 20.9-21.5 MHz
10 m A: 27.9-28.5 MHz
10 m B: 28.5-29.1 MHz (Optional)
10 m C: 28.9-29.5 MHz (Optional)
WWV: 9.9-10.5 MHz (Optional)
Plus Three more optional 600 KHz Bands |
| Modes: |
AM/SSB/CW (FM option) |
| Memories: |
N/A |
| Tuning Steps: |
Analog / Continuous |
| Voltage: |
Mains: 100 / 117 / 220 / 240 VAC |
| Current Drain: |
~50 W |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
381 x 181 x 298 mm (15 x 7.12 x 11.75 inches) |
| Weight: |
12 Kg (26.46 lb) |
| Manufactured: |
Japan: 1965-196x (Discontinued) |
| Other: |
Matching Companion Transmitter, The Yaesu FL-100B |
| Related Documents: |
User Manual (4.2 MB) |
