| Type: |
HF/VHF/UHF Receiver/Scanner |
| Frequency Range: |
0.1-1300 MHz (Cellular blocked in the US) |
| Modes: |
AM/FM/WFM |
| RF Power output: |
N/A |
| Sensitivity: |
AM (10 dB S/N)
0.2-5 MHz: 1.5 uV
5-160 MHz: 0.6 uV
160-370 MHz: 0.6 uV
FM (12 dB SINAD)
5-520 MHz: 0.3 uV
520-1300 MHz: 0.7 uV
WFM (12 dB SINAD)
5-160 MHz: 0.9 uV
160-370 MHz: 0.6 uV
370-520 MHz: 1.0 uV
520-1300 MHz: 3.0 uV
|
| Selectivity: |
AM/FM: 16 KHz (-6 dB)
WFM: 200 KHz (-6 dB) |
| Image rejection: |
N/A |
| Voltage: |
2.2-3.5 VDC (2*R6/AA) or 5.5-10 VDC (external) |
| Current Drain: |
15-95 mA |
| Aerial Input: |
50 ohms, BNC |
| Dimensions (W*H*D): |
59*85*26 mm |
| Weight: |
195 gr |
| Manufactured: |
Japan, 2001-200x |
| Other: |
640 memories in 10 banks. Alpha tags. "Frequency finder".
Dual watch. Built-in ferrite bar for MW reception. |
| Related Documents: |
User Manual (635 Kb) |
