| Type: |
Amateur VHF Transceiver |
| Frequency Range: |
TX: 144-148 /430-450 MHz (USA)
RX: 0.5-999 MHz (Cellular blocked) |
| Modes: |
TX: FM/NFM/DV (C4FM FDMA, 9.6 Kbps)
RX: AM/FM/NFM/DV (C4FM FDMA, 9.6 Kbps) |
| RF Power output: |
Hi: 5/5 W
Mid: ?/? W
L1: ?/? mW
L2: ?/? mW |
| Frequency Steps: |
5 / 6.25 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 KHz |
| Sensitivity: |
140-150 MHz: 0.16 uV (12 dB SINAD)
400-470 MHz: 0.18 uV (12 dB SINAD) |
| Selectivity: |
AM/FM: 12 KHz (-6 dB), 35 KHz (-60 dB) |
| Voltage: |
7.4 VDC |
| Current Drain: |
RX: 240 mA (+30 mA GPS on) (+80 mA Digital on)
TX: Max 2 A |
| Aerial Input: |
50 ohms, SMA |
| Dimensions: |
60 x 95 x 28 mm |
| Weight: |
265 gr (With FNB-101Li and antenna) |
| Manufactured: |
2012-20xx |
| Other: |
Built-in GPS. IPX5 water spray resistant. Vibralert. Internal AM bar antenna.
GSM function (Group Short Message, 80 characters). Micro SD card slot.
Snapshot function/Image transfer with optional camera-microphone.
Digital ARTS. USB port |
