Yaesu FT-203R
| Type: |
Amateur VHF Transceiver |
| Frequency range: |
144-146 MHz (Europe and Asia)
144-148 MHz (USA) |
| Modes: |
FM |
| RF Power output: |
2.5 W |
| Sensitivity: |
0.25 uV (12 dB SINAD)
1 uV (30 dB S/N) |
| Selectivity: |
+/- 6 KHz (- 6 dB)
+/- 12 KHz (-60 dB) |
| Image rejection: |
N/A |
| Voltage: |
5.5-13 VDC |
| Current drain: |
RX: 20-100 mA
TX: 700 mA |
| Aerial Input: |
50 ohms, BNC |
| Dimensions (W*H*D): |
65*153*34 mm |
| Weight: |
450 gr |
| Manufactured: |
198x-198x (late eighties) |
| Other: |
PLL with thumbwheels. VOX
|
| Related documents: |
User Manual (3.9 MB)
|
|
