| Type: |
Amateur VHF Transceiver |
| Frequency range: |
144-146 MHz |
| Modes: |
FM |
| RF Power output: |
Lo: 500 mW
Hi{ 2-5 W |
| Frequency Steps: |
5 / 10 / 12.5 / 20 / 25 KHz |
| Voltage: |
5.5-15 VDC |
| Current drain: |
RX: 6-150 mA
TX: Max 1.3 A |
| Aerial Input: |
50 ohms, BNC |
| Dimensions (W*H*D): |
55 x 126 x 32 mm (2.16 x 4.96 x 1.26 inches), with FBA-17 |
| Weight: |
360 gr (12.7 oz), with FBA-17 and YHA-16 |
| Manufactured: |
Japan: 198x-198x (Discontinued) |
| Other: |
DTMF. AFC. VOX. Memory cloning. |
| Related documents: |
|
