Yaesu FT-225R
| Type: |
Amateur VHF Transceiver |
| Frequency Range: |
144-148 MHz |
| Modes: |
AM/FM/SSB/CW |
| RF Power output: |
SSB: 24 W
FM/CW: 25 W
AM: 8 W |
| Sensitivity: |
SSB/CW: 0.3uV for 10 dB S/N
FM: 0.3uV for 20 dB QS
AM: 1.0uV for 10 dB S/N
400 Hz 30% Modulation |
| Selectivity: |
SSB/CW/AM: 2.3kHz at 6 dB Down
SSB/CW/AM: 4.1kHz at 60 dB Down
FM: 12kHz at 6 dB Down
FM: 28kHz at 60 dB Down |
| Image rejection: |
Better than -60 dB |
| Voltage: |
12 VDC or Mains |
| Current Drain: |
RX: ? mA
TX: Max 5 A |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
280 x 125 x 315 mm |
| Weight: |
9.0 Kg |
| Manufactured: |
1978-19xx |
| Other: |
Digital readout |
