| Type: |
Amateur VHF Transceiver |
| Frequency Range: |
144-146 MHz |
| Modes: |
FM/SSB/CW |
| RF Power output: |
Hi: 2.5 W
Lo: 0.5 W |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
9.6-12 VDC (8x LR14/C Batteries)
8.5-15.2 VDC external (Barrel Connector, Center Negative) |
| Current Drain: |
RX: 60 mA
TX: Max 800 mA |
| Aerial Input: |
50 ohms, SO-239 or Built-In Telescopic Whip |
| Dimensions (W*H*D): |
150 x 58 x 195 mm (5.9 x 2.28 x 7.68 inches) |
| Weight: |
1.3 Kg (2.87 lb), Without Batteries |
| Manufactured: |
Japan, 198x-198x (Discontinued) |
| Other: |
10 regular Memories
RAM storage with lithium battery backup |
| Related Documents: |
|
