| Type: |
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-146 / 430-440 MHz (Europe)
TX: 144-148 / 430-450 MHz (USA)
RX: 108-520 / 700-1000 MHz (Cellular Blocked in USA) |
| Modes: |
TX: FM/NFM
RX: AM/FM/NFM |
| RF Power output: |
Hi: 50/35 W
Lo 3: 20/20 W
Lo 2: 10/10 W
Lo 1: 5/5 W |
| Memories: |
512 Regular in 10 Banks. Alpha Tags
5 Home
10 Scan Edge Pairs (PMS)
6 hyper
1 Priority
Non-volatile EEPROM storage |
| Voltage: |
13.8 VDC ±15% ("T" Connector on Pigtail) |
| Current Drain: |
RX: 500 mA (Squelched)
TX: Max 8.5 A |
| Aerial Input: |
50 ohm, SO-239 |
| Dimensions (W*H*D): |
140 x 42 x 168 mm (5.51 x 1.65 x 6.61 inches) |
| Weight: |
1 Kg (2.2 lb) |
| Manufactured: |
Japan: 2003-2016 (Discontinued) |
| Other: |
CTCSS/PL.
DCS with tone search. DTMF.
1K2/9K6 packet jack.
ARTS. WIRES internet.
Cross-band repeater.
Data cloning.
Twin RX. |
| Related Documents: |
User Manual (756 kb) |
