| Type: |
Amateur HF/VHF Transceiver |
| Frequency Range: |
TX: 160M - 6M ( AMateur Bands only)
RX: 30KHZ - 60MHz (operating, 160M - 6M ( Sepcified performance AmateurBands only
|
| Modes: |
A1A (CW) A3E (AM), J3E (SSB), F3E (FM), F1B (RTTY), F1D (PACKET) |
| RF Power output: |
5-100 W
2-25 W (AM Carrier) |
| Frequency Steps: |
1/10Hz (SSB,CW & AM) 100Hz *FM) |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: Max 2.1 A
TX: Max 22 A |
| Aerial Input: |
50 ohms unbalanced: 160M ~ 10M Amateur Bands; Tuner ON: 16.7 ~150Ohms |
| Dimensions (W*H*D): |
14.4" x 4.5" x 12.4" ( 365 x 115 x 315 mm) |
| Weight: |
21.6lbs (9.8Kg) |
| Manufactured: |
2009-20xx |
| Other: |
DSP.127 memories. RS-232C. FM option.Twin RX. |
| Related Documents: |
Operating Manual (6.99 MB)
Pre-Release Manual (427 Kb) |
