| Type: | Amateur VHF Transceiver |
| Frequency Range: | TX: 430-440 MHz or 430-450 MHz RX: 430-440 MHz or 420-470 MHz |
| Modes: | FM |
| RF Power output: | Max 5 W |
| Memories: | 200 |
| Frequency Steps: | 5/10/12.5/15/20/25/50/100 kHz |
| Image rejection: | N/A |
| Voltage: | 7.2 VDC |
| Current Drain: | RX: Max 130 mA TX: Max 1.8 A |
| Aerial Input: | 50 ohms |
| Dimensions (W*H*D): | 60 x 120 x 32 mm |
| Weight: | 390 gr |
| Manufactured: | |
| Other: | CTCSS and DCS Built In Alpha/Numeric Labeling (up to six characters) |
| Related Documents: | User Manual (2.64 MB) |
