| Type: | Amateur VHF/UHF Transceiver |
| Frequency Range: | TX: 144-146 / 430-440 MHz (Europe and Asia) RX: 0.5-1.7 / 76-999 MHz |
| Modes: | TX: FM RX: AM/FM/WFM |
| RF Power output: | 0.5 / 0.5 W (1/1 W with external power) |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 3.6 VDC (3.2-7 VDC external) |
| Current Drain: | RX: 16-150 mA TX: 0.4 A @ 500 mW TX output |
| Aerial Input: | 50 ohms, SMA |
| Dimensions (W*H*D): | 47*81*25 mm |
| Weight: | 125 gr |
| Manufactured: | 1997-19xx |
| Other: | |
| Related Documents: | User Manual (1.28 MB) Brochure (1.08 MB) |
