Yaesu VX-8E
| Type: |
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 50-54 / 144-146 / 430-440 MHz (Europe)
TX: 50-54 / 144-148 / 222-225 / 440-450 MHz (USA)
RX: 0.5-999 MHz (Cellular blocked in the US) |
| Modes: |
TX: AM/FM
RX: AM/FM/WFM |
| RF Power output: |
Hi: 5/5/5 W
Low3: 2.5/2.5/2.5 W
Low2: 1/1/1 W
Low1: 0.5/0.5/0.5 W
0.3 W (220 MHz, FM), 1 W (50 MHz, AM) |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
7.4 VDC (internal), 10-16 VDC (external) |
| Current Drain: |
RX: 25-200 mA
TX: 0.6-1.8 A |
| Aerial Input: |
50 ohms, SMA |
| Dimensions (W*H*D): |
2.36" x 3.74" x 0.92" |
| Weight: |
240 gr |
| Manufactured: |
2008-200x |
| Other: |
500 memories. Waterproof/submersible. Twin RX |
| Related Documents: |
Brochure (4.24 MB) |
 |
