| Type: |
Amateur VHF/UHF transceiver |
| Frequency Range: |
TX: 50-54 / 144-148 / 222-225 / 440-450 MHz
RX: 0.6-999.9 MHz (Cellular blocked) |
| Mode: |
TX: FM
RX: AM/FM/WFM |
| RF Power output: |
Hi: 5/5/1.5/5 W
Mid: ?/?/?/? W
Lo: ?/?/?/? mW |
| Voltage: |
7.4 VDC (1100 mAh Lithium Ion pack)
3*R6/AA dry cell case option. |
| Current Drain: |
RX: ? mA
TX: ? A |
| Impedance: |
50 ohms, SMA |
| Dimensions (W*H*D): |
60*95*23 mm |
| Weight: |
? gr |
| Manufactured: |
2008-200x |
| Other: |
Waterproof/submersible (IPX57). Built-in packet modem 1200/9600bd
with APRS support. Bluetooth and GPS options. Barometric sensor.
Weather alert. Alpha tags. Spectrum display. CTCSS/DCS. Twin RX. |
| Related Documents: |
User Manual (5.22 MB)
Brochure (4.24 MB) |
