| Type: |
Citizen Band Transceiver |
| Frequency Range: |
Export Mode: 24.885-30.105 MHz
10M Mode: 28.0-29.7 MHz
10 NOAA: weather channels or 140-170 MHz (RX only) |
| Channels: |
?? (10 / 100 Hz, 1 / 5 / 10 / 100 KHz, 1 MHz steps) |
| Modes: |
AM/FM/SSB/CW |
| Frequency Control: |
PLL |
| Power Output: |
AM: 1-12 W
FM/CW: 1-40 W
SSB: 1-35 W |
| Voltage: |
13.8 VDC (3-Pin Connector) |
| Current Drain: |
RX: 300-700 mA
TX: Max 3 A |
| Dimensions (W*H*D): |
158 x 48 x 252 mm (6.22*1.89*9.92")
6.22 x 1.89 x 9.92 inches |
| Weight: |
1.27 Kg
2.8 lbs |
| Manufactured: |
China: 2023-202x
New price: £273.86 (From Radioddity, February 2026) |
| Other: |
PA. ANL/NB. ASQ. Repeater shift/offset. CTCSS/PL and DCS. Scanning.
SWR meter. Tone hi-cut. DTMF function. Dual Watch .
Roger Beep. +10 KHz function. Noise Reduction (NRC).
VOX. Echo. Dimmer. Multicolor backlight. PC programmable. |
| Related Documents: |
User Manual (3.7 MB) |
| Sams Photofact: |
|
| FCC Data (ID): |
|
