| Type: |
Professional Marine transceiver |
| Frequency Range: |
RX: 1.6-23 MHz
TX: 1.6-23 MHz |
| Modes: |
AM/SSB/CW/RTTY |
| RF Power Output: |
AM: Max 37.5 W
SSB: Max 150 W PEP
CW: Max 75 W |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
10.8-15.6 VDC |
| Current Drain: |
RX: 1.2 A
TX: Max 30 A |
| Aerial Input: |
? ohms |
| Dimensions (W*H*D): |
250 x 100 x 280 mm (8.9 x 3.9 x 11 inches) |
| Weight: |
5.8 Kg (12.8 lb) |
| Manufactured: |
1988-199x (Discontinued) |
| Other: |
Optional Accessory: AT-1500 Automatic Antenna Coupler (1.6-25 MHz 150W PEP) |
| Related Documents: |
Owner's Manual (3.3 MB)
Service Manual (6.5 MB) |
