| Type: |
Professional Marine Transceiver |
| Frequency Range: |
TX: 156.050-157.425 MHz
RX: 156.050-163.275 |
| Modes: |
FM |
| channels: |
All international, US and Canadian channels
NOAA Weather Channels |
| RF Power Output: |
25/1 W |
| Voltage: |
12 VDC system (13.6 VDC, typical |
| Current Drain: |
RX: 0.6-2 A
TX: Max 6 A |
| Aerial Input: |
50 ohms SO:259 |
| Dimensions (W*H*D): |
167 x 73 x 175 mm (6.57 x 2.87 x 6.89in) |
| Weight: |
1.13 kg (2.5 lbs) |
| Manufactured: |
201x-201x (Discontinued) |
| Other: |
See Manual |
| Related Documents: |
Owner's Manual (4.53 MB) |
