| Type: |
Professional Marine Transceiver |
| Frequency Range: |
TX: 155-165 MHz
RX: 155-165 MHz |
| Modes: |
FM |
| Memories: |
3 Regular Channels
9 optional Channels
2 Weather Channels
Crystal Controlled |
| RF Power Output: |
Hi: 25 W
Lo: 1 W |
| Voltage: |
13 VDC (4-Pin Jones Connector) |
| Current Drain: |
RX: ? A
TX: Max ? A |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
298 x 100 x 347 mm
(11.7 x 3.94 x 13.7 inches) |
| Weight: |
? Kg |
| Manufactured: |
USA: 197x-197x (Discontinued) |
| Other: |
|
| Related Documents: |
|
