| Type: | Amateur VHF Transceiver |
| Frequency Range: | TX: 144-146 MHz (138-175 MHz) RX: 138-175 MHz |
| Mode: | FM |
| RF Power output: | Hi: 5 W Mid: 2.5 W Lo: 0.35 W |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 5-16 VDC |
| Current Drain: | RX: 15-? mA TX: 350-950 mA |
| Aerial Input: | 50 ohms, BNC |
| Dimensions (W*H*D): | 55*84*31 mm (battery excluded) |
| Weight: | 185 gr (without battery and antenna) |
| Manufactured: | 199x-199x |
| Other: | 20 memories |
| Related Documents: |
