| Type: |
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-146 / 432-436 MHz
RX: 100-173 / 350-469.95 MHz
5/10/12.5/20/25/50/100 KHz steps |
| Mode: |
TX: FM
RX: AM/FM |
| RF Power output: |
Hi: 5/5 W
Mid: 2.5/2.5 W
Lo: 0.5/0.35 W |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
6-16 VDC |
| Current Drain: |
RX: 17-? mA
TX: 0.5-1.3 A |
| Aerial Input: |
50 ohms, BNC |
| Dimensions (W*H*D): |
65*92*38 mm (battery excluded) |
| Weight: |
? gr |
| Manufactured: |
xxxx-xxxx |
| Other: |
Twin RX |
| Related Documents: |
|
