Baofeng UV-B6
| Type: |
Private Mobile Radio |
| Frequency Range: |
TX/RX: 146-174 MHz
TX/RX: 400-470 MHz
RX: 65-108 MHz |
| Mode: |
FM |
| RF Power output: |
1W/5W |
| Memories: |
99 |
| Frequency Steps: |
5/6.25//10/12.5/20/25 kHz |
| Tones: |
DCS/CTCSS codec: 104-DCS, 50-CTCSS |
| Voltage: |
7.4 VDC (Li-ion Rechargable Battery) |
| Current Drain: |
RX: Max ? mA
TX: Max ? A |
| Aerial Input: |
50 ohms |
| Dimensions (W*H*D): |
? mm |
| Weight: |
? gr |
| Manufactured: |
20xx-20xx |
| Other: |
|
| Related Documents: |
User Manual (2.12 MB) |
|
