Yaesu VX-1210
| Type: |
Private Mobile Radio |
| Frequency Range: |
TX: 1.6-30 MHz
RX: 0.5-30 MHz |
| Mode: |
AM/SSB/CW/AFSK |
| RF Power output: |
Hi: 20 W, Lo: 5 W
AM Hi: 10 W, AM Lo: 2.5 W |
| Sensitivity: |
0.5 uV (10 dB S/N) |
| Selectivity: |
2.4 KHz (-6 dB), 5 KHz (-60 dB) |
| Image rejection: |
80 dB |
| Voltage: |
14.4 VDC (Lithium-Ion battery) |
| Current Drain: |
RX: 0.1-0.5 A
TX: 3-5 A |
| Aerial Input: |
50 ohms |
| Dimensions (W*H*D): |
193*74*274 mm |
| Weight: |
3.2 Kg (with battery) |
| Manufactured: |
199x-200x |
| Other: |
500 memories |
| Related Documents: |
|
|
