Alinco DJ-S1T
| Type: |
Amateur VHF Transceiver |
| Frequency Range: |
TX: 144-148 MHz
RX: 118-136 / 140-170 MHz AM/FM |
| Modes: |
TX: FM
RX: AM/FM |
| RF Power output: |
Hi: 2-5 W (depending on voltage)
Mid: 1 W
Lo: 100 mW |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
? VDC |
| Current Drain: |
RX: Max ? mA
TX: Max ? mA |
| Aerial Input: |
50 ohms, BNC |
| Dimensions (W*H*D): |
2.1*4.3*1.5 inches |
| Weight: |
13 oz (with DR-y battery case) |
| Manufactured: |
199x-199x |
| Other: |
DTMF option |
| Related Documents: |
|
|
