| Type: |
Amateur VHF Transceiver |
| Frequency Range: |
TX: 144-148 / 222-225 MHz
RX: 136-174 / 222-225 MHz |
| Modes: |
FM |
| RF Power output: |
Hi: 45/25 W
Mid: 10/10 W
Lo: 5/5 W |
| Sensitivity: |
Less than 0.16 uV for 12 dB SINAD |
| Selectivity: |
More than 15 KHz/-6 dB
Less than 30 KHz/-60 dB |
| Image rejection: |
N/A |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: Max 1.2 A
TX: Max 10.5 A |
| Aerial Input: |
50 ohms |
| Dimensions (W*H*D): |
140*40*165 mm |
| Weight: |
1.25 Kg |
| Manufactured: |
19xx-19xx |
| Other: |
Twin RX |
| Related Documents: |
|
