| Type:
|
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-146 / 430-440 MHz
RX: 136-174 / 400-470 MHz |
| Modes: |
FM |
| RF Power output: |
Hi: 5/5 W
Mid: 0.5/0.5 W
Lo: 15/15 mW |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
4.8-9.6 VDC with battery pack or 4.5-16 VDC external |
| Current Drain: |
RX: 30-170 mA
TX: Max 1.6 A |
| Aerial Input: |
50 ohms |
| Dimensions (W*H*D): |
57*125*31 mm |
| Weight: |
320 gr (with BP-170) |
| Manufactured: |
Japan, 1995-19xx |
| Other: |
50+50 memories. CTCSS, DTMF. Twin RX |
| Related Documents: |
User Manual (4.0 MB) |
