Kenwood R-5000
| Type: |
HF Receiver |
| Frequency Range: |
0.1-30 MHz |
| Modes: |
AM/FM/SSB/CW |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
13.8 VDC or Mains |
| Current Drain: |
Max 2 A |
| Aerial Input: |
50/500 ohms |
| Dimensions (W*H*D): |
270*96*270 mm |
| Weight: |
5.6 Kg |
| Manufactured: |
Japan, 1987-1996 |
| Other: |
100 memories. RX 108-174 MHz option (VC-20) |
| Related Documents: |
User Manual (1.35 MB)
Service Manual (12.8 MB) |
 |
