Yaesu FT-680R
| Type: |
Amateur VHF Transceiver |
| Frequency Range: |
50-54 MHz |
| Modes: |
AM/FM/SSB/CW |
| RF Power output: |
10 W (AM: 5 W) |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: 500 mA
TX: Max 3 A |
| Aerial Input: |
50 ohms, SO-239 |
| Dimensions (W*H*D): |
180*60*240 mm |
| Weight: |
2.9 Kg |
| Manufactured: |
Japan, 19xx-19xx |
| Other: |
|
| Related Documents: |
|
|
