| Type: |
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-146 / 430-440 MHz (Europe)
TX:144-148 / 430-450MHz (USA)
RX: 108-180 / 320-480 / 810-1000 MHz * |
| Modes: |
TX: FM
RX: AM/FM |
| RF Power output: |
Hi: 50/35 W
Mid1: 20/20 W
Mid2: 10/10 W
Lo: 5/5 W |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
13.8 VDC |
| Current Drain: |
RX: Max 0.5 A
TX: Max 11.5 A |
| Aerial Input: |
50 ohms, SO-239 (N-type for Europe) |
| Dimensions (W*H*D): |
140*38*166 mm |
| Weight: |
1.0 Kg |
| Manufactured: |
Japan, 2001-200x |
| Other: |
262 memories. Detachable head. CTCSS & DCS
ARTS. 9K6 packet ready. Twin RX. * Cellular blocked in the US |
