| Type: | Amateur VHF Transceiver |
| Frequency Range: | TX: 430-440 MHz or 430-450 MHz RX: 430-440 MHz or 420-470 MHz |
| Modes: | FM |
| RF Power output: | Max 5 W |
| Frequency Steps: | 5, 10, 12.5, 15, 20, 25, 50, 100 kHz |
| Voltage: | 7.2 VDC |
| Current Drain: | RX: Max 130 mA TX: Max 1.8 A |
| Aerial Input: | 50 ohms |
| Dimensions (W*H*D): | 60 x 120 x 32 mm |
| Weight: | 390 gr (with Antenna & Belt Clip) |
| Manufactured: | 200x-20xx |
| Other: | Emergency Automatic ID (EAI) function TOT. APO. ARS, ARTS |
| Related Documents: | Operating Manual (3.00 MB) |
