| Type: |
Amateur VHF/UHF Transceiver |
| Frequency Range: |
TX: 144-148/430-450 MHz
RX: 108-999 MHz |
| Modes: |
TX: FM
RX: AM/FM/WFM |
| RF Power output: |
Hi: 5/5 W
Low3: 2.5/2.5 W
Low2: 1/1 W
Low1: 0.5/0.5 W |
| Frequency Steps: |
5/6.25/8.33/10/12.5/15/20/25/50/100 kHz |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
7.4 VDC (internal), 10-16 VDC (external) |
| Current Drain: |
RX: 25-200 mA
TX: 0.6-1.8 A |
| Aerial Input: |
50 ohms, SMA |
| Dimensions (W*H*D): |
60 x 95 x 28 mm |
| Weight: |
250 gr |
| Manufactured: |
20xx-20xx |
| Other: |
|
| Related Documents: |
User Manual (3.97 MB) |
